Pepperl+Fuchs KCD2-SR-Ex1.LB Switch Amplifiers Isolated Barriers

Pepperl+Fuchs KCD2-SR-Ex1.LB Switch Amplifiers Isolated Barriers

Description

The KCD2-SR-Ex1.LB is a highly efficient 1-channel isolated barrier tailored for intrinsic safety applications in industrial environments. It enables the secure transfer of digital signals from NAMUR sensors or mechanical contacts located in hazardous areas to safe areas. This device is equipped with a form A normally open relay contact designed for safe area loads. Its compact housing, only 12.5 mm wide, makes it an ideal solution for applications where space is at a premium. The normal output state can be reversed using switch S1, providing flexibility in system design. Additionally, switch S3 allows users to enable or disable line fault detection of the field circuit, enhancing operational safety and reliability. In the event of an error condition, such as a fault in the field circuit, the relays revert to their de-energized state, and the LEDs on the device indicate the fault in accordance with NAMUR NE44 standards. This feature ensures quick identification and resolution of issues, minimizing downtime. The KCD2-SR-Ex1.LB operates within a temperature range of -20°C to 60°C, making it suitable for a wide range of industrial settings.

Features

The device is powered by a rated voltage of 19 to 30 V DC and consumes a maximum of 500 mW of power, ensuring energy efficiency without compromising performance. Its low heat dissipation further contributes to the stability and longevity of the device in demanding environments. The KCD2-SR-Ex1.LB is designed to be mounted on a 35 mm DIN rail, adhering to EN 60715 standards, which simplifies installation and integration into existing systems. The housing material, polycarbonate (PC), offers excellent durability and resistance to harsh environmental conditions, including exposure to dust and moisture. The protection degree of IP20 ensures that the device is protected against solid objects larger than 12 mm in diameter, making it suitable for indoor applications in controlled environments.

Function

One of the standout features of the KCD2-SR-Ex1.LB is its ability to detect positions, end stops, and switching states in space-critical applications. This makes it an invaluable tool for factory automation, process control, and hazardous area signal management. The device’s robust construction and adherence to international standards, such as NAMUR NE23 for digital inputs and NAMUR NE44 for LED indicators, ensure that it meets the stringent requirements of industrial safety protocols. Whether used in oil and gas refineries, chemical plants, or other hazardous environments, the KCD2-SR-Ex1.LB provides reliable and safe signal isolation and transmission, protecting both personnel and equipment. Its certification for use in hazardous locations further underscores its reliability and suitability for critical applications where safety and performance are paramount.

KCD2-SR-Ex1.LB

KFD2-SR2-Ex1.W

KFA5-SR2-Ex1.W

KFA6-SR2-Ex1.W

KFD2-SR2-Ex1.W.LB

KFA5-SR2-Ex1.W.LB

KFA6-SR2-Ex1.W.LB

KCD2-SR-Ex2

KFD2-SR2-Ex2.W

KFA5-SR2-Ex2.W

KFA6-SR2-Ex2.W

KFA5-SR2-Ex2.W.IR

KFA6-SR2-Ex2.W.IR

KFD2-SR2-Ex2.2S

KFD2-SRA-Ex4

KFD2-SR-Ex1.4S.LK

KFD2-ST2-Ex1.LB

KFD2-ST2-Ex2

KFD2-SOT2-Ex1.LB

KFD2-SOT2-Ex1.LB.IO

KFD2-SOT2-Ex1.N

KFD2-SOT2-Ex2

KFA5-SOT2-Ex2

KFA6-SOT2-Ex2

KFD2-SOT2-Ex2.IO

KFD2-SH-Ex1

KFD2-SH-Ex1.T.OP

KHA6-SH-Ex1

KFD2-DU-Ex1.D

KFA5-DU-Ex1.D

KFA6-DU-Ex1.D
