G2R-2A4-Z Omron G2R Series Power PCB Relay
The Omron G2R Series Power PCB Relay is a versatile and reliable relay designed for industrial applications. Here's a comprehensive description:
Overview
The G2R Series relays are general-purpose power relays featuring single-pole 10 A and double-pole 5 A configurations. They have a compact and space-saving design, making them suitable for various Industrial Automation, electrical control, and power distribution systems. With a safety-oriented design, they offer a dielectric strength of 5,000 V between the coil and contacts, and a surge resistance of 10,000 V, ensuring reliable operation in harsh environments. The series includes AC and DC types for operational coils, providing flexibility in different power supply scenarios.
Features and Specifications
The G2R Series relays come in a variety of configurations to meet different application requirements. They have a contact resistance of up to 100 mΩ, an operating time of up to 15 ms, and a release time of up to 10 ms for AC and 5 ms for DC (20 ms max. with a built-in diode). Their maximum operating frequency is 18,000 operations per hour mechanically and 1,800 operations per hour electrically under rated load. They also have an insulation resistance of 1,000 MΩ min. at 500 VDC and can withstand dielectric strength tests of 5,000 VAC or 1,000 VAC between different components.
Applications
The G2R Series relays are widely used in industrial automation for controlling motors, solenoids, and other actuators. They are suitable for use in power distribution systems to switch power on and off, and can be used in circuit breaker control circuits to provide overcurrent protection. Their compact size and high reliability make them ideal for use in control panels and electrical cabinets where space is limited and reliable operation is critical. They can also be used in the control circuits of various machinery and equipment to achieve automated control functions.
G2R Series：
G2R-1A
G2R-2A
G2R-2
G2R-1A4
G2R-14
G2R-2A4
G2R-24
G2R-2A-H
G2R-2-H
G2R-1A-H
G2R-1-H
G2R-1A-T
G2R-1-T
G2R-1A-Z
G2R-1-Z
G2R-2A-Z
G2R-2A4-Z
G2R-2-Z
G2R-2A4-U
G2R-14-U
G2R-2A4-U
G2R-1A4-U
