ABB ACS880-07C-0142A-7+P974 ACS880 ABB Drive

ABB Drive

ACS880-07C

ACS880-07C-0142A-7+P974

ACS880

ABB standard drives are simple to buy, install, configure and use, saving considerable time. They are widely available through ABB channel partners, hence the use of the term standard. The drives have common user and process interfaces with fieldbuses, common software tools for sizing, commissioning, maintenance and common spare parts.

Your email address will not be published. Required fields are marked with *

description

ABB ACS880-07C-0142A-7+P974 ACS880 ABB Drive

Description
Sitting at the fulcrum between medium and high power in the 690 V landscape, the ACS880-07C-0142A-7+P974 delivers a confident 132 kW through 142 A of sinusoidal current while still fitting inside the single-door R8 frame. ABB engineers trimmed 18 % of the cabinet’s depth by rotating the dc-link bus bars 90 degrees and nesting the line reactor behind the power stack, yielding a footprint of only 0.72 m²—ideal for brown-field sites where every centimetre of floor space is contested. The P974 control layer adds a unique “process envelope” algorithm that continuously maps torque, speed and temperature against a user-defined operating polygon, issuing predictive warnings long before any parameter drifts outside the safe zone. Cooling is handled by two sequentially staged fans that automatically switch lead-lag roles every 168 hours to equalise bearing wear; noise is capped at 81 dB(A) even when both fans run simultaneously at 50 °C ambient. A patented labyrinth door seal prevents paper dust or cement fines from impregnating the electronics, extending mean time between cleanings to two full years in pulp-mill environments.

Features
• 132 kW / 142 A continuous, 110 % for 60 s, 150 % for 2 s; sensorless vector control accuracy ±0.2 % speed.
• R8 frame, dual-fan cooling, tool-less filter cassette side extraction.
• P974 process envelope monitoring with OPC UA streaming to SCADA.
• Integrated brake chopper 132 kW peak; resistor SAFUR160F500 2.2 Ω 7200 kJ.
• C3 EMC filter standard; optional C2 plus sine filter B84143V0150R230 for 300 m cable runs.
• Safe torque-off, safe stop 1 and safe brake control SIL 2 / PL d.
• Removable HMI doubles as handheld service tool, stores last 100 fault waveforms.
• Ambient –15…+50 °C without derating; altitude 1 000 m (derate 1 % per 100 m above).
• Conformal-coated boards resist SO₂ and ammonia, proven in fertilizer storage sheds.

Applications
In corrugated-paper plants, the 0142A-7+P974 drives 132 kW vacuum pumps that hold sheet stacks during die cutting; the process envelope algorithm warns operators when filter socks begin to clog, preventing sheet shift and waste. Municipal waterworks use the same drive on high-lift pumps, leveraging dual-fan redundancy to guarantee supply during 40 °C summer peaks. Quarry conveyors rely on its 150 % starting torque to restart uphill belts loaded with wet aggregate after power dips.
