ABB 3ABD00046078-D ACQ580-04-820A-4 ACQ580 ABB Drive

ABB 3ABD00046078-D ACQ580-04-820A-4 ACQ580 ABB Drive

Description

The ACQ580-04-820A-4 is a cabinet-mounted inverter designed for water and wastewater treatment. It has a rated power of 384.0 kW and provides an output current of 820.0 A at 400 V. The inverter operates within a voltage range of 380–480 V AC and features an IP54 enclosure, offering protection against dust and water spray in both indoor and outdoor environments. Its robust design makes it suitable for installation in harsh industrial settings. By incorporating ABB's active front end (AFE) technology, the inverter reduces harmonic distortion to less than 3% THDi, eliminating the need for external filters. This ensures stable operation and protects sensitive instruments and equipment in water and wastewater treatment facilities. Additionally, the conformal coating on the internal PCBs enhances its resistance to harsh environmental conditions such as humidity and corrosive gases like hydrogen sulfide (H₂S), thereby extending its service life in sewage treatment plants and other challenging environments.

Features

The inverter is equipped with intelligent pump-specific functions such as dry-run protection, which automatically stops pump operation when fluid loss is detected, preventing pump damage and ensuring system reliability. The soft pipe fill function allows for gradual pressure build-up, effectively preventing water hammer effects that can damage pipes and cause system failures. The sensorless flow calculation capability eliminates the need for external flow meters, simplifying system configuration and reducing maintenance requirements while accurately controlling and monitoring flow rates. It offers dual hardware interfaces that support multiple communication protocols, including CAN, Modbus RTU, PROFIBUS, Ethernet/IP, and USB, enabling seamless integration with various PLC systems and automation networks. The Drive Composer PC tool further enhances its configurability and diagnostic capabilities, making it easy to clone parameters and monitor inverter performance in real-time. This simplifies system setup, commissioning, and troubleshooting processes. The ECO mode dynamically adjusts motor torque based on actual load conditions during partial load operation, resulting in significant energy savings of 15–25% and reduced operational costs while maintaining efficient system performance. The integrated kWh/CO₂ calculator allows users to track energy consumption and carbon emissions in real-time, helping them evaluate and optimize the energy efficiency and environmental impact of their operations. Safety is a top priority for this inverter, featuring Safe Torque Off (STO) and motor thermistor monitoring functions that ensure SIL3/PLd-certified fail-safe shutdowns in the event of faults or emergencies, effectively protecting personnel and equipment and minimizing potential risks in industrial environments.

Applications

The ACQ580-04-820A-4 is well-suited for a variety of water and wastewater applications. In water supply systems, it can be used to control pumps in residential water booster systems, ensuring stable water pressure and flow rates for residential complexes of different sizes. In wastewater treatment plants, it efficiently drives chemical dosing pumps, precisely controlling the dosing of chemicals to ensure effective wastewater treatment while avoiding overdosing or underdosing. With a rated power of 384.0 kW, it can handle flow rates of up to 3,840 m³/h, making it capable of meeting the demands of large water and wastewater treatment facilities. Its excellent harmonic immunity makes it suitable for use in pharmaceutical or food-processing facilities where sensitive laboratory equipment is present. The cabinet-mount design also makes it a robust solution for outdoor installations in harsh industrial environments, providing reliable power and control for water supply and distribution in various settings.

ACQ580-01-02A7-43ABD50000039015

ACQ580-01-03A4-4 3ABD50000039016

ACQ580-01-04A1-4 3ABD50000039017

ACQ580-01-05A7-4 3ABD50000039018

ACQ580-01-07A3-4 3ABD50000039019

ACQ580-01-09A5-4 3ABD50000039020

ACQ580-01-12A7-4 3ABD50000039021

ACQ580-01-018A-4 3ABD50000039027

ACQ580-01-026A-4 3ABD50000039028

ACQ580-01-033A-4 3ABD50000039029

ACQ580-01-039A-4 3ABD50000039030

ACQ580-01-046A-4 3ABD50000039031

ACQ580-01-062A-4 3ABD00045422-D

ACQ580-01-073A-4 3ABD00045423-D

ACQ580-01-089A-4 3ABD00060201-D

ACQ580-01-106A-4 3ABD00045425-D

ACQ580-01-145A-4 3ABD00045426-D

ACQ580-01-169A-4 3ABD00045427-D

ACQ580-01-206A-4 3ABD00045428-D

ACQ580-01-246A-4 3ABD00045429-D

ACQ580-01-293A-4 3ABD00045430-D

ACQ580-01-363A-4 3ABD00045431-D

ACQ580-01-430A-4 3ABD00045432-D

ACQ580-04-505A-4 3ABD00046074-D

ACQ580-04-585A-4 3ABD00046075-D

ACQ580-04-650A-4 3ABD00046076-D

ACQ580-04-725A-4 3ABD00046077-D

ACQ580-04-820A-4 3ABD00046078-D

ACQ580-04-880A-4 3ABD00046079-D
